| GENERAL SPECIFICATION |
| Winding type： | YWE |
| Hall effect angle： | 120 Deg. Electrical angle |
| Radial play： | 0.02mm /450g |
| End play： | 0.08mm /450g |
| Max. radial force： | 2N @ 10mm from the flange |
| Max. axial force： | 10N |
| Insulation class： | B |
| Dielectric strength： | 500VDC for one minute |
| Insulation resistance： | 100MΩ min., 500VDC |
| PERFORMANCE DATA |
| Model | Number of poles | Number of phase | Rated voltage | Rated speed | Continuous stall torque | Rated torque | Rated power | Peak torque |
| Units | VDC | RPM | mN.m | mN.m | W | mN.m | ||
| 33BYA036B150X-01 | 4 | 3 | 24 | 15000 | 14.16 | 11.8 | 18.5 | 35.4 |
| 33BYA036B200X-01 | 24 | 20000 | 14.16 | 11.8 | 25 | 35.4 | ||
| 33BYA036A200X-01 | 12 | 20000 | 14.16 | 11.8 | 25 | 35.4 |
| Model | Peak current | Torque constant | Back E.M.F | Rotor inertia | Body length | Voltage range | Speed Range | Weight |
| Units | A | Nm/A | V/KRPM | g.c㎡ | mm | VDC | RPM | Kg |
| 33BYA036B150X-01 | 3 | 11.8×10-3 | 1.5 | 2.33 | 36 | 12~24 | 4000~22000 | 0.1 |
| 33BYA036B200X-01 | 4.05 | 9×10-3 | 1.09 | 2.33 | 0.1 | |||
| 33BYA036A200X-01 | 8.1 | 4.5×10-3 | 0.54 | 2.33 | 0.1 |
| OUTLINE MAP |
